Name: 30mm Stroke Terminal Applicator Vertical Feed Otp Vertical Crimping Die for Versatile
Brand: Yihan, hxn
Price: 180.00 USD

Place of Origin : Guangdong, China

Brand Name : Yihan, hxn

Model Number : OTP, YH terminal applicator

Usage : Crimping

Net Weight : 5.5KG

Name : vertical feed terminal

Stroke : 30mm

Appication : vertical feed terminal

Function : Terminal crimping

Type : Automatic or manual

Packaging Details : wooden package

Price : $180.00/sets 1-2 sets

MOQ : 1 set

Contact Now

30mm Stroke Terminal Applicator Vertical Feed Otp Vertical Crimping Die for Versatile

High quality full automatic wire wut strip twist and terminal crimping machine

Terminal applicator terminal mould OTP mould/Applicator vertical feed terminal

Specification:

Product Features:

Adapt to a variety of cross-transmission terminal.
Push terminals adjustable spacing.
Plastic bag in the rotating blades can fine-tune knob
Cast iron body, durable
tailor-made molds connection to use under the head

30mm Stroke Terminal Applicator Vertical Feed Otp Vertical Crimping Die for Versatile

Product Description

Material belt	Single grain type	Horizontal type	Straight type
Net Weight	4.0KG	5KG	5.5KG
Dimensions	W180H160D110mm
Stroke	30mm
Suitable wire range	0.08-6mm2
Shut height	135.8mm
Suitable for the material thickness of terminal	1.2mm(max)
Feeding mechanism	pneumatic
Feed step distance	35mm(max)
Alignment accuracy	0.02mm
Slide Adjustment	2mm
Air Pressure	0.6-0.8mpa

30mm Stroke Terminal Applicator Vertical Feed Otp Vertical Crimping Die for Versatile
